Basic Specifications
Model NO.
GB-4430-06
Excitation Mode
Compound
Function
Driving
Casing Protection
Closed Type
Number of Poles
8
Structure and Working Principle
Brush
Type
PMDC
Certification
CCC, CE/RoHS
Voltage
6V-24V
Speed
10-200rpm
Power
30-60W
Gear Ratio
Customize
Hall Sensor
Customize
Transport Package
Carton Packing
Specification
35*30*25cm
Origin
China
Production Capacity
5000PCS Per Day
Product Description
The height adjustment range, adjustment speed, noise level, and load capacity of an electric height-adjustable table are determined by the technical specifications of the motor used. Generally, an automatic height-adjustable table can choose an electric height-adjustable column motor! An electric height-adjustable column motor is a new type of electric height-adjustable device developed for realizing the height adjustment of various smart furniture work platforms. It mainly consists of an electric linear actuator motor and a control device, an extendable outer sleeve, etc. The electric height-adjustable column motor has the characteristics of low noise operation, large extension range, smooth operation, beautiful appearance, simple installation, and convenient operation. When combined with a controller, it can realize the adjustment of the electric height-adjustable column to any desired height at the adjustment position, meeting the needs of smart furniture products for freely adjusting the height. Therefore, the electric height-adjustable column motor is an ideal electric height-adjustable drive for an electric height-adjustable table.
ℹ
Performance datasheet:
| Voltage |
DC 12-29V |
| Power |
60W max |
| Torque |
8N.m max |
| Speed |
200rpm |
| Hall sensor |
Double hall sensor |
| Gear ratio |
39:1 |
| Brake |
with brake |
| Support weight |
120kg |
Frequently Asked Questions
?
What factors determine the load capacity and adjustment speed of a height-adjustable table?
The overall height adjustment range, adjustment speed, operating noise level, and carrying capacity of an electric height-adjustable table are completely determined by the technical specifications of the column motor integrated into the system.
?
What are the core components of an electric height-adjustable column motor?
It primarily consists of a high-performance electric linear actuator motor, a dedicated control unit system, and an extendable protective outer sleeve configured for seamless movement.
?
What are the primary operational characteristics of this column motor?
This electric height-adjustable column motor is characterized by its exceptionally low noise operation, extensive height extension range, smooth transitions, sleek aesthetic design, straightforward installation, and highly intuitive operation.
?
What weight capacity can this motor support?
According to the performance datasheet, the motor is robustly designed to support a maximum weight capacity of up to 120kg, making it ideal for heavy-duty smart office and furniture configurations.
?
Can the height adjustments be controlled precisely?
Yes. When integrated with a system controller, the double Hall sensor and standard 39:1 gear ratio allow the motor to precisely adjust the columns to any targeted height position smoothly.
